Upgrade Your Build with Our Crocodile FRD5030 Dual-Output DC Motor Speed Controller – Precision, Power, and Versatility in One Compact Unit

Need a smart, reliable, and high-performance motor controller for projects that require dual motor outputs? Our advanced Dual-Output DC Motor Controller is designed for EV conversions, robotics, and industrial applications where independent, synchronized control is a must.

Multi-Mode Control for Ultimate Flexibility

Our Crocodile FRD5030 Motor Speed Controller offers seamless plug-and-play compatibility with a wide range of control interfaces, so you can tailor the input method to your system:

• Standard potentiometer or hall-effect throttle (0.8–4.2V)
• Joystick mode for intuitive dual-axis control
• Direct PWM signal input (0–95%)
• RC PWM receiver input (1.5ms ±1ms)
• Full serial communication via TX/RX for advanced setups and real-time adjustments

Built-In Protection with Intelligent Current Limiting

With dual-channel current limiting, the controller protects both motors from overload. Set the continuous current per channel from 0–30A, while peak current supports 2×50A. Ideal for balanced power delivery and safe operation in demanding conditions.

Regenerative Braking + 4-Quadrant Drive

Experience smooth bidirectional control with 4-quadrant operation – drive or brake in either direction, and recover kinetic energy directly into your power source via regenerative braking. Perfect for battery-powered systems where efficiency is key.

Key Features of the Crocodile FRD5030 Motor Speed Controller:

Dual-output reversible DC motor controller

• 4 input modes: potentiometer, hall throttle, joystick, direct PWM, RC PWM
• Full serial TX/RX communication for advanced parameter control
• 4-quadrant regenerative operation
• High-speed 32-bit Cortex processor for responsive, stable control
• Smooth 18kHz switching frequency
• Adjustable acceleration ramp (0–40 seconds)
• Universal 0–5V control signal compatibility (PLC, analog, PWM, RC)
• Thermal protection at 70°C (158°F)
• Duty cycle control: 0–100%
• Dual current limit: 0–30A each (peak 2×50A)
• Wide voltage input: 6–50V DC
• Compact design: 106 × 75 × 25 mm | Weight: 130g (bare board)

Stay Cool Under Load

To maintain top performance during high-demand operations, we recommend active fan cooling, especially when pushing both outputs to peak current. Proper cooling = longer lifespan + stable output.

Why Choose Our Crocodile FRD5030 Motor Speed Controller ?

Whether you’re engineering a dual-motor EV, building an autonomous robot, or powering synchronized industrial systems, this controller offers next-level control, safety, and efficiency in a compact form.

Upgrade your project with confidence—experience the next generation of motor control with our dual-output solution.
